Automatic Bed Sheet Two-side Hemming Machine
Suitable for continuous double-sided hemming and cutting of fabrics in home textile products manufacturing,such as bed sheets,flat sheets,and curtains.
.png)
Please wait a moment. The video is loading...
Equipment Advantages
- Full servo control with GetonAgain HMI; control cabinet position customizable.
- Feeding unit handles both roll and panel fabrics, with no-material detection, auto alignment and edge trimming as standard; optional semi-automatic fabric splicer and waste collector.
- Fabric pulling unit automatically advances material to preset length.
- Longitudinal sewing head (lock-stitch, optional chain-stitch) movable for maintenance; sewing width 1500-3000 mm; hemming device 12-100 mm adjustable; thread-break auto-stop; auto-oiling.
- Rotary blade cross-cutter with optional ultrasonic edge sealing.
- Material buffer synchronizes sewing, pulling and cutting for continuous flow.
- Discharge conveyor laterally ejects stacked sheets when preset count reached.
| Model | Working Area (mm) | Power (kw) | Machine Installation Size (L×W×H) |
|---|---|---|---|
| GOA-AS | 1500mm-3000mm | 12KW | 11000mm×7000mm×2000mm |
